698A 100kg to1000kg alumninum single point load cell For Platform scale 2.0 ±10%mV/V OIML C3
698A 100kg to1000kg alumninum single point load cell For Platform scale 2.0 ±10%mV/V OIML C3
Model
698A

Item specifics

load cell type
single point type
material
alumninum
Sensitivity
2.0 ±10%mV/V
Application
Platform scale
Accuracy class
OIML C3
Zero balance
0.02mV/V
Creep over 30min
0.02%
Repeatability
0.017%
protection
IP67
Hysteresis
0.017%

Review

Description

Single point load cell

Comply with OIML C3 up to 5000 division
Off-center load compensated
IP67 protection
CE certificated
For Platform scale

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 100/200/300/500/635/ 1,000
Accuracy class  C3
Sensitivity mV/V 2.0 ±10%
Platform size mm750*750
Zero balance mV/V0.02
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket

interchangeable with Vishay HBM,Mettler Toledo Load cell

Good quality and long life with competitive price!
