658A 50kg to 300kg single point load cell For platform scale

Group single point load cell
Min. Order 1 piece
Terms of Payment all
Update Time 2019-10-23
Item specifics
load cell typesingle point type
materialalumninum
Applicationplatform scale
Accuracy classC3
capacity50/60/80/100/150/200/300kg
Creep over 30min0.023%
Repeatability0.017%
Zero balance0.06mV/V
Sensitivity2.0 ±10%mV/V
Hysteresis0.017%
  • Description
  • Product review

High accuracy regulations up to 5 000d for
scales class III
CE certificated
Off-Center compensated
For platform scale

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 50/60/80/100/150/200/300
Accuracy class  C3
Sensitivity mV/V 2.0 ±10%
Platform size mm450 450
Zero balance mV/V0.06
Creep over 30min %0.023
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket

interchangeable with Vishay HBM,Mettler Toledo Load cell
