608A 500kg to 2000kg single point load cell

Group single point load cell
Min. Order 1 piece
Terms of Payment all
Update Time 2019-01-16
Item specifics
load cell typesingle point type
materialalumninum
Applicationelectronic price scale,platform scale
capacity500/750/1000/2000kg
Accuracy classC3
Sensitivity2.± 10%mV/V
Zero balance0.02mV/V
Repeatability0.017%
Creep over 30min0.023%
Max.platform size500kg 600 800mm
  • Description
  • Product review

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 500/750/1000/2000
Accuracy class  C3
Sensitivity mV/V2.± 10%
Zero balance mV/V0.02
Creep over 30min %0.023
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0017
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350± 3
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht
