651 500g 1000g 2000g aluminum single point C3 load cell sensor for precision balance 1.2 ±10%mV/V
651 500g 1000g 2000g aluminum single point C3 load cell sensor for precision balance 1.2 ±10%mV/V
Model
651

Item specifics

material
aluminum
load cell type
single point load cell
Application
precision balance,electronic balance
Accuracy class
OIML C3, OIML C6
capacity
500g 1000g 2000g
Sensitivity
1.2 ±10%mV/V
Zero balance
0.02mV/V
Creep over 30min
0.008%
Hysteresis
0.01,0.012%
Repeatability
0.01%

Review

Description


Rated capacity (Emax) g 500/1000/2000
Huazhun Grade  A
Sensitivity mV/V1.2 ±10%
Zero balance mV/V0.02
Creep over 30min %0.008
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0012
Hysteresis % 0.01 0.012
Linearity deviation % 0.01
Repeatability % 0.01
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 200
Break load % of R.C. 300
Nominal excitation V 5 ~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 0.35
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc-Red, +Sig-Grn, -Exc-Blk, -Sig- Wht

interchangeable with Vishay HBM,Mettler Toledo Load cell

Good quality and long life with competitive price!

High accuracy load cell for jewellery scale

Suitable for Jewellery scale-651 series
