613A 100kg to 20000kg single ended load cell for floor scale
613A 100kg to 20000kg single ended load cell for floor scale
Price
US $35
Model
613A
Min. Order
1 piece

Item specifics

material
alloy steel
capacity
100kg~20,000kg
Accuracy class
OIML C3
Application
floor scale,hopper scale,and all kinds of weighing devices.
Interchangeable with
Rice Lake RL30000
Sensitivity
3.0± 0.25%mV/V
Creep over 30min
0.02%
Zero balance
0.02mV/V
Repeatability
0.017%
Hysteresis
0.017%

Product review

Description

Interchangeable with Vishay-Tedea 3411, Rice Lake RL30000, suitable for floor scale...
CE certificated

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 100/200/300/500/1000/2000/2500/4000/5000/10,000/15,000/20,000
Accuracy class  C3
Sensitivity mV/V3.0± 0.25%
Zero balance mV/V0.02
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 18
Input impedance  380 ±25
Output impedance  350± 5
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-Grn, -Exc-Blk, -Sig- Wht

Interchangeable Products   Celtron  SQB
  Rice Lake  RL30000
  Rice Lake  RL35023
  Revere  5123
  Sensortronics  65023
  Tedea  3411

interchangeable with Vishay HBM,Mettler Toledo Load cell
