616A 1000kg to 300000kg Disk load cell for motion weighing

616A 1000kg to 300000kg Disk load cell for motion weighing
Model
616A

Item specifics

Capacity
1,000kg...300,000kg
material
alloy steel
IP Rating
Ip67
Application
motion weighing
Accuracy class
0.3
Sensitivity
2.0 ±10%mV/V
Zero balance
0.04mV/V
Creep over 30min
0.1%
Repeatability
0.017%

Product review

Description

interchangeable with Vishay HBM,Mettler Toledo Load cell

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 25/50/200/500/1,000/2,000/3,000/5,000/10,000/20,000/30,000
Accuracy class  0.3
Sensitivity mV/V2.0 ±10%
Zero balance mV/V0.04
Creep over 30min %0.1
Temperature effect on zero %/ 0.0012
Temperature effect on output %/ 0.0023
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -10 to +50
Limit load % of R.C. 150
Break load % of R.C. 300
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  400 ±25
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc-Red, +Sig -Grn, -Exc-Blk, -Sig- Wht
