636A Tension and compresion load cell for motion weighing
636A Tension and compresion load cell for motion weighing
Model
636A

Item specifics

Capacity
1,000kg...300,000kg
material
alloy steel
Application
motion weighing
IP Rating
Ip67
Accuracy class
0.3
Sensitivity
2.5 ±10%mV/V
Zero balance
0.005mV/V
Creep over 30min
0.1%
Repeatability
0.05%

Product review

Description

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 5,000/10,000/25,000/50,000/100,000
Accuracy class  0.3
Sensitivity mV/V2.5 ±10%
Zero balance mV/V0.005
Creep over 30min %0.1
Temperature effect on zero %/ 0.046
Temperature effect on output %/ 0.016
Hysteresis % 0.32
Linearity deviation % 0.32
Repeatability % 0.05
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 300
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  400 ±25
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc-Red, +Sig -Grn, -Exc-Blk, -Sig- Wht

interchangeable with Vishay HBM,Mettler Toledo Load cell

Good quality and long life with competitive price!
