617BS 10000 to 100000kg Column load cell for truck scale
617BS 10000 to 100000kg Column load cell for truck scale
Model
617BS

Item specifics

load cell type
Column load cell
Material
stainless steel or alloy steel
Usage
load cell for truck scale
Accuracy class
OIML C3 standard
Application
truck scale
Capacity
10000 to 100000kg
Sensitivity
2.5 ±0.002mV/V
Zero balance
1mV/V
Creep over 30min
0.02%
Repeatability
0.017%

Product review

Description

interchangeable with Vishay HBM,Mettler Toledo Load cell

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 10,000...100,000
Accuracy class  C3
Sensitivity mV/V2.5 ±0.002
Zero balance mV/V1
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +65
Limit load % of R.C. 120
Break load % of R.C. 150
Nominal excitation V 5~12
Max. excitation V 18
Input impedance  450 ±4.5
Output impedance  480 ±4.8
Insulation resistance M >5000
Cable length M 5.5
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht

Type: Column load cell
