647BS 10000kg to 50000kg Column load cell for truck scale

Group Column load cell
Min. Order 1 piece
Terms of Payment all
Update Time 2019-10-23
Item specifics
Load cell structureColumn load cell
Materialstainless steel
StandardOIML C3
usageload cell for truck scale
Capacity10000kg to 50000kg
IP RatingIP 68
Sensitivity2.0 ±0.002mV/V
Zero balance1mV/V
Creep over 30min0.02%
  • Description
  • Product review

interchangeable with Vishay HBM,Mettler Toledo Load cell

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 10,000...50,000
Accuracy class  C3
Sensitivity mV/V2.0 ±0.002
Zero balance mV/V1
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Nominal temperature range  -10 to +40
Service temperature range  -40 to +80
Limit load % of R.C. 150
Break load % of R.C. 300
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  700± 7
Output impedance  703 ±4
Insulation resistance M >2000
Cable length M 15
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc-Red, +Sig -Grn, -Exc-Blk, -Sig- Wht
Construction  Stainless steel
Protection class to IEC529  IP 68
