637BS 10000kg to 100000kg Column load cell for truck scale
637BS 10000kg to 100000kg Column load cell for truck scale
Model
637BS

Item specifics

material
stainless steel
standard
OIML C3 standard
type
column load cell
usage
load cell for truck scale
Capacity
10000kg to 100000kg
Accuracy class
C3
Sensitivity
1.5± 0.002mV/V
Zero balance
2mV/V
Creep over 30min
0.02%

Product review

Description

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 10,000...100,000
Accuracy class  C3
Sensitivity mV/V1.5± 0.002
Zero balance mV/V2
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Nominal temperature range  -10 to +40
Service temperature range  -35 to +65
Limit load % of R.C. 150
Break load % of R.C. 300
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  700 ±7
Output impedance  703 ±4
Insulation resistance M >2000
Cable length M 10,000kg...30,000 12m, 40,000...100,000 20m
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc-Red, +Sig -Grn, -Exc-Blk, -Sig- Wht
Construction  Stainless steel
Protection class to IEC529  IP 68

Load cell type: Column load cell

Usage: this column load cell widely used in truck scale

interchangeable with Vishay HBM,Mettler Toledo Load cell
