643B 5Klb to 250klb alloy steel Double ended load cell weight sensor for truck scale OIML C3
643B 5Klb to 250klb alloy steel Double ended load cell weight sensor for truck scale OIML C3
Model
643B

Item specifics

material
alloy steel,stainless steel available
Accuracy class
OIML C3 standard
Application
truck scale
capacity
5Klb to 250klb
Sensitivity
3.0± 0.1%mV/V
Creep over 30min
0.02%
Zero balance
0.01mV/V
Hysteresis
0.017%
Repeatability
0.017%
Linearity deviation
0.017%

Review

Description

interchangeable with Vishay HBM,Mettler Toledo Load cell

Good quality and long life with competitive price!

Double ended load cell for truck scale

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) Klb 5/10/20/30/40/50/60/75/100/150/200/250
Accuracy class  C3
Sensitivity mV/V3.0± 0.1%
Zero balance mV/V0.01
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 120
Break load % of R.C. 150
Nominal excitation V 5
Max. excitation V 12
Input impedance  700± 7
Output impedance  703± 4
Insulation resistance M >5000
Cable length M 6
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig -Grn, -Exc-Blk, -Sig- Wht
