Load cell 653B 1Klb to 75klb C3 alloy steel Double ended beam weight force sensor IP66 for truck scale weighbridge 3.0 ±0.008mV/V
- Model
- 653B
Item specifics
- material
- alloy steel，stainless steel available
- Capacity
- 1Klb~75klb
- Accuracy class
- OIML C3 standard
- Application
- truck scale
- Sensitivity
- 3.0 ±0.008mV/V
- Zero balance
- 0.01mV/V
- Creep over 30min
- 0.02%
- Repeatability
- 0.017%
- Linearity deviation
- 0.017%
- Hysteresis
- 0.017%
Review
Description
interchangeable with Vishay HBM,Mettler Toledo Load cell
Good quality and long life with competitive price!
Double ended load cell for truck scale, Weighbridge and Platform Scale
Edit Text
| PARAMETER | UNIT | TECHNICAL DATA |
|---|---|---|
| Rated capacity (Emax) | Klb | 1/1.5/2/2.5/4/5/10/15/20/25/35/50/75 |
| Accuracy class | C3 | |
| Sensitivity | mV/V | 3.0 ±0.008 |
| Zero balance | mV/V | 0.01 |
| Creep over 30min | % | 0.02 |
| Temperature effect on zero | %/ | 0.004 |
| Temperature effect on output | %/ | 0.0014 |
| Hysteresis | % | 0.017 |
| Linearity deviation | % | 0.017 |
| Repeatability | % | 0.017 |
| Nominal temperature range | -10 to +40 | |
| Service temperature range | -30 to +70 | |
| Limit load | % of R.C. | 120 |
| Break load | % of R.C. | 150 |
| Nominal excitation | V | 5~12 |
| Max. excitation | V | 18 |
| Input impedance | 700± 7 | |
| Output impedance | 703± 4 | |
| Insulation resistance | M | >5000 |
| Cable length | M | 6 |
| Cable type | 4 conductors, Braid Shielded, Black PVC Jacket | |
| Color code | +Exc-Red, +Sig-Grn, -Exc-Blk, -Sig- Wht |
