663B 50Klb to 250klb Double ended load cell load cell for truck scale

Group Double ended load cell
Min. Order 1 piece
Terms of Payment L/C, Western Union, T/T, Paypal
Update Time 2019-10-15
Item specifics
materialalloy steel,stainless steel available
Capacity50Klb~250klb
Accuracy classOIML C3 standard
Sensitivity3.0 ±0.003mV/V
Zero balance0.03mV/V
Creep over 30min0.02%
Repeatability0.017%
Linearity deviation0.017%
Hysteresis0.017%
Input impedance700 ±7
  • Description
  • Product review

interchangeable with Vishay HBM,Mettler Toledo Load cell

Edit Text

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) Klb 50/60/65/75/100/125/150/200/250
Accuracy class  C3
Sensitivity mV/V3.0 ±0.003
Zero balance mV/V0.03
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 120
Break load % of R.C. 150
Nominal excitation V 5~12
Max. excitation V 18
Input impedance  700 ±7
Output impedance  703 ±4
Insulation resistance M >5000
Cable length M 6
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht
