635N 5t to 30t Aluminum S Type load cell weight sensor for crane scale IP65
635N 5t to 30t Aluminum S Type load cell weight sensor for crane scale IP65
Model
635N

Item specifics

material
Aluminum
Accuracy class
OIML C3 standard
Application
crane scale,and other weighing devices
IP Rating
IP65
Capacity
5t to 30t
Sensitivity
2.0 ±10%mV/V
Zero balance
0.02mV/V
Creep over 30min
0.02%
Repeatability
0.017%

Review

Description

interchangeable with Vishay HBM,Mettler Toledo Load cell

Good quality and long life with competitive price!

S Type load cell for crane scale,and other weighing devices.

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 5,000...30,000
Accuracy class  C3
Sensitivity mV/V2.0 ±10%
Zero balance mV/V0.02
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0017
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +65
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 18
Input impedance  350± 10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 0.5
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht
