Load cell 625B 1kg to 30kg 0.02% 5-12V Aluminum S Type weight force sensor for Crane scale mechanical conversioin scale hopper scale C3 IP67 2.0± 0.25mV/V
- Model
- 625B
Item specifics
- Accuracy class
- OIML C3 standard
- material
- Aluminum
- IP Rating
- Ip67
- Application
- Crane scale mechanical conversioin scale,Hopper scale and other weighing devices
- Capacity
- 1kg to 30kg
- Sensitivity
- 2.0± 0.25mV/V
- Zero balance
- 0.02mV/V
- Creep over 30min
- 0.02%
- Repeatability
- 0.017%
- Hysteresis
- 0.017%
Review
Description
interchangeable with Vishay HBM,Mettler Toledo Load cell
Good quality and long life with competitive price!
S type load cell for crane scale mechanical conversioin scale,Hopper scale and other weighing devices
| PARAMETER | UNIT | TECHNICAL DATA |
|---|---|---|
| Rated capacity (Emax) | kg | 1/3/5/10/15/20/30 |
| Accuracy class | C3 | |
| Sensitivity | mV/V | 2.0± 0.25 |
| Zero balance | mV/V | 0.02 |
| Creep over 30min | % | 0.02 |
| Temperature effect on zero | %/ | 0.004 |
| Temperature effect on output | %/ | 0.0017 |
| Hysteresis | % | 0.017 |
| Linearity deviation | % | 0.017 |
| Repeatability | % | 0.017 |
| Nominal temperature range | -10 to +40 | |
| Service temperature range | -30 to +65 | |
| Limit load | % of R.C. | 150 |
| Break load | % of R.C. | 200 |
| Nominal excitation | V | 5~12 |
| Max. excitation | V | 15 |
| Input impedance | 380 ±25 | |
| Output impedance | 350± 3 | |
| Insulation resistance | M | >2000 |
| Cable length | M | 2 |
| Cable type | 4 conductors, Braid Shielded, Black PVC Jacket | |
| Color code | +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht |
