635B 25kg to 30000kg alloy steel S Type load cell weight sensor for crane scale OIML C3
635B 25kg to 30000kg alloy steel S Type load cell weight sensor for crane scale OIML C3
Model
635B

Item specifics

material
alloy steel
load cell type
S Type load cell
Accuracy class
OIML C3 standard
Application
crane scale
IP Rating
IP65 IP66/IP67
Capacity
25kg to 30000kg
Sensitivity
2.0± 0.025(Metric) 3.0± 0.028(Imperial)mV/V
Zero balance
0.02mV/V
Creep over 30min
0.02%
Repeatability
0.017%

Review

Description

interchangeable with Vishay HBM,Mettler Toledo Load cell

Good quality and long life with competitive price!

S Type load cell for crane scale

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 25...30,000(100lb...20Klb)
Accuracy class  C3
Sensitivity mV/V2.0± 0.025(Metric) 3.0± 0.028(Imperial)
Zero balance mV/V0.02
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0017
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +65
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 18
Input impedance  350 ±10
Output impedance  350± 3
Insulation resistance M >2000
Cable length M 3
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht
