618A 0.3kg to 6kg aluminum single point load cell weight sensor for Industrial control system IP 66
- Model
- 618A
Item specifics
- material
- aluminum
- load cell type
- single point load cell
- application
- Industrial control system and education equipment
- capacity
- 0.3 0.5 1 2 3 6kg
- Accuracy class
- OIML C3
- Zero balance
- 0.02mV/V
- Creep over 30min
- 0.023%
- Repeatability
- 0.017%
- IP Rating
- IP 66
- Hysteresis Error
- 0.017%
Review
Description
| PARAMETER | UNIT | TECHNICAL DATA | |
|---|---|---|---|
| Rated capacity (Emax) | kg | 0.1/0.2/0.3 /0.5 | 1/2/3/5 |
| Accuracy class | C3 | C3 | |
| Sensitivity | mV/V | 1.0 ±20% | 2.0± 20% |
| Zero balance | mV/V | 0.02 | |
| Creep over 30min | % | 0.023 | 0.023 |
| Temperature effect on zero | %/ | 0.012 | 0.001 |
| Temperature effect on output | %/ | 0.0017 | 0.0012 |
| Hysteresis | % | 0.023 | 0.017 |
| Linearity deviation | % | 0.023 | 0.017 |
| Repeatability | % | 0.023 | 0.017 |
| Nominal temperature range | -10 to +40 | ||
| Service temperature range | -30 to +70 | ||
| Limit load | % of R.C. | 150 | |
| Break load | % of R.C. | 300 | |
| Nominal excitation | V | 5~12 | |
| Max. excitation | V | 15 | |
| Input impedance | 405 ±10 | ||
| Output impedance | 350 ±3 | ||
| Insulation resistance | M | >2000 | |
| Cable length | M | 0.4 | |
| Cable type | 4 conductors, Braid Shielded, Black PVC Jacket | ||
| Color code | +Exc -Red, +Sig-Grn, -Exc-Blk, -Sig- Wht | ||
| Construction | Aluminum | ||
| Protection class to IEC529 | IP 66 | ||
interchangeable with Vishay HBM,Mettler Toledo Load cell
Good quality and long life with competitive price!
Capacity 0.3kg to 6kg can be customized
