618D 3kg to 50kg single point load cell for pricing scale
618D 3kg to 50kg single point load cell for pricing scale
Model
618D

Item specifics

material
alumninum
load cell type
single point type
Max.platform size
250 ×350mm
IP Rating
IP66
application
pricing scale,counting scale,Code scale
Sensitivity
2. ±10%mV/V
Accuracy class
C3
Creep over 30min
0.023%
Repeatability
0.017%
Hysteresis
0.017%

Product review

Description

interchangeable with Vishay HBM,Mettler Toledo Load cell

Single point load cell-618D
is aluminum load cell
CE certificated
Comply with OIML C3

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 3/5/8/20/30/50
Accuracy class  C3
Sensitivity mV/V2. ±10%
Zero balance mV/V0.02
Creep over 30min %0.023
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0017
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht
