Weight force sensor 678A 250kg alumninum single point load cell IP66 for platform bench scale C3 2.0± 0.25%mV/V
Weight force sensor 678A 250kg alumninum single point load cell IP66 for platform bench scale C3 2.0± 0.25%mV/V

Weight force sensor 678A 250kg alumninum single point load cell IP66 for platform bench scale C3 2.0± 0.25%mV/V

Model
678A

Item specifics

load cell type
single point type
material
alumninum
Application
platform scale
Accuracy class
OIML C3
Sensitivity
2.0± 0.25%mV/V
Zero balance
0.02mV/V
Creep over 30min
0.02%
Hysteresis
0.017%
Repeatability
0.017%
Capacity
250kg

Review

Description

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 250
Accuracy class 　C3
Sensitivity mV/V 2.0± 0.25%
Platform size mm550 600
Zero balance mV/V0.02
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range 　-10 to +40
Service temperature range 　-30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance 　405 ±10
Output impedance 　350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type 　4 conductors, Braid Shielded, Black PVC Jacket
interchangeable with Vishay HBM,Mettler Toledo Load cell
Good quality and long life with competitive price!
