668A 60kg to 300kg single point load cell for platform scale

Group single point load cell
Min. Order 1 piece
Terms of Payment all
Update Time 2019-01-16
Item specifics
load cell typesingle point type
Applicationplatform scale
materialalumninum
capacity60kg to 300kg
Accuracy classC3
IP RatingIP66
Sensitivity2.0 ±10%mV/V
Creep over 30min0.02%
Zero balance0.06mV/V
Repeatability0.017%
Description

Comply with OIML C3
scales class III
Off-center load compensated
IP66 protection
For platform scale

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 60/100/150/200/300
Accuracy class  C3
Sensitivity mV/V 2.0 ±10%
Platform size mm500 500
Zero balance mV/V0.06
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Eccentric loading error % /cm 0.0042
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 300
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 2
