Load cell 688B 50kg to 635kg alumninum single point weight sensor for Medical weighing IP67
Load cell 688B 50kg to 635kg alumninum single point weight sensor for Medical weighing IP67

Load cell 688B 50kg to 635kg alumninum single point weight sensor for Medical weighing IP67

Model
688B: 50kg~635kg

Item specifics

material
alumninum

Review

Description

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 50/75/100/150/200
Accuracy class 　C3
Sensitivity mV/V 2.0 ±10%
Platform size mm600 600
Zero balance mV/V0.02
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range 　-10 to +40
Service temperature range 　-30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance 　405 ±10
Output impedance 　350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type 　4 conductors, Braid Shielded, Black PVC Jacket
Interchangeable with Vishay HBM,Mettler Toledo Load cell
Good quality and long life with competitive price!
