688A 60kg to 750kg single point load cell for platform scale

688A 60kg to 750kg single point load cell for platform scale
Model
688A 60kg 100kg 200kg 300kg 500kg 600kg 750kg

Item specifics

load cell type
single point type
material
alumninum
application
platform scale,belt scale,Mesical weighing
capacity
60 100 150 200 300 500 600 750kg
protection
Ip67
Accuracy class
OIML C3
Sensitivity
2.0 ±10%mV/V
Creep over 30min
0.02%
Repeatability
0.017%
Hysteresis
0.017%

Product review

Description

interchangeable with Vishay HBM,Mettler Toledo Load cell

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 60/ 100/200/300/500/600/750
Accuracy class  C3
Sensitivity mV/V 2.0 ±10%
Platform size mm600 700
Zero balance mV/V0.02
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
