651F 4kg 5kg 8kg 10kg 20kg single point load cell for precision balance

Group single point load cell
Min. Order 1 piece
Terms of Payment all
Update Time 2019-10-24
Item specifics
load cell typesingle point type
materialalumninum
capacity4kg 5kg 8kg 10kg 20kg
Applicationelectronic price scale,electronic pacling scale
Accuracy classC3
Sensitivity2 ±0.2mV/V
Zero balance0.04mV/V
Creep over 30min0.02%
Repeatability0.017%
  • Description
  • Product review

interchangeable with Vishay HBM,Mettler Toledo Load cell

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 4/5/8/10/20
Accuracy class  C3
Sensitivity mV/V2 ±0.2
Zero balance mV/V0.04
Creep over 30min %0.02
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0012
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~15
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 0.4
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc-Red, +Sig -Grn, -Exc-Blk, -Sig- W
