628A 3kg to100kg single point load cell for electronic balances
628A 3kg to100kg single point load cell for electronic balances
Model
628A

Item specifics

material
aluminum
load cell type
single point load cell
Usage
weighing scale
Accuracy class
OIML C3, OIML C6
capacity
3/6/10/15/20/25/30/35/40/50/60/100kg
Sensitivity
2.0 ±10%mV/V
Zero balance
0.02mV/V
Creep over 30min
0.008%
Application
electronic balances,pricing scale

Product review

Description

interchangeable with Vishay HBM,Mettler Toledo Load cell

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 3/6/10/15/20/25/30/35/40/50/60/100
Huazhun Grade  A
Sensitivity mV/V 2.0 ±10%
Platform size mm250 350(300 380)
Zero balance mV/V0.02
Creep over 30min %0.008
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0014
Hysteresis % 0.01
Linearity deviation % 0.01
Repeatability % 0.01
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 0.5
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
