load cell 651E 500g 1000g 2000g aluminum single point weight sensor IP66 OIML C3 for jewellery scale 1.0 ±10%mV/V
- Model
- 651E
Item specifics
- material
- aluminum
- load cell type
- single point load cell
- Application
- high precision balance,electronic balance
- Accuracy class
- OIML C3, OIML C6
- capacity
- 500g 1000g 2000g
- standard
- C6
- protection
- IP66
- Sensitivity
- 1.0 ±10%mV/V
- Zero balance
- 0.02mV/V
- Creep over 30min
- 0.008%
Review
Description
| PARAMETER | UNIT | TECHNICAL DATA |
|---|---|---|
| Rated capacity (Emax) | g | 500/1000/2000 |
| Huazhun Grade | A | |
| Sensitivity | mV/V | 1.0 ±10% |
| Zero balance | mV/V | 0.02 |
| Creep over 30min | % | 0.008 |
| Temperature effect on zero | %/ | 0.004 |
| Temperature effect on output | %/ | 0.0012 |
| Hysteresis | % | 0.01 0.012 |
| Linearity deviation | % | 0.01 |
| Repeatability | % | 0.01 |
| Nominal temperature range | -10 to +40 | |
| Service temperature range | -30 to +70 | |
| Limit load | % of R.C. | 150 |
| Break load | % of R.C. | 200 |
| Nominal excitation | V | 5 ~12 |
| Max. excitation | V | 15 |
| Input impedance | 405 ±10 | |
| Output impedance | 350± 3 | |
| Insulation resistance | M | >2000 |
| Cable length | M | 0.35 |
| Cable type | 4 conductors, Braid Shielded, Black PVC Jacket | |
| Color code | +Exc-Red, +Sig-Grn, -Exc-Blk, -Sig- Wht |
interchangeable with Vishay HBM,Mettler Toledo Load cell
Good quality and long life with competitive price!
High accuracy IP66 single point load cell for jewellery scale
