651D 1kg to 20kg single point load cell for precision balance

Group single point load cell
Min. Order 1 piece
Terms of Payment L/C, Western Union, T/T, Paypal
Update Time 2019-10-14
Item specifics
materialaluminum
load cell typesingle point load cell
Applicationelectronic balance
Accuracy classOIML C4,C5,C6
capacity1kg to 20kg
Sensitivity1.5 ±10%mV/V
Zero balance0.02mV/V
Creep over 30min0.023%
Hysteresis0.017%
Repeatability0.017%
  • Description
  • Product review

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 1/2/3/5/8/10/15/20
Accuracy class  C3
Sensitivity mV/V1.5 ±10%
Zero balance mV/V0.02
Creep over 30min %0.023
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.0017
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 0.4
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht

interchangeable with Vishay HBM,Mettler Toledo Load cell
