635A 50 to 10000kg alloy steel OIML C3 S Type load cell weight sensor for crane scale 2± 0.25%mV/V
635A 50 to 10000kg alloy steel OIML C3 S Type load cell weight sensor for crane scale 2± 0.25%mV/V
Price
US $35
Model
635A
MOQ
1 piece

Item specifics

material
alloy steel
load cell type
S Type load cell
Application
Crane scale mechanical conversioin scale
Accuracy class
OIML C3 standard
Capacity
500kg to 10ton
Interchangeable Products
Tedea 615
Sensitivity
2± 0.25%mV/V
Zero balance
0.04mV/V
Creep over 30min
0.03%
IP Rating
IP66/IP67

Review

Description

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 50/100/300/500/1,000/SE-2,000/2,000/3,000/5,000/10,000
Accuracy class  C3
Sensitivity mV/V2± 0.25%
Zero balance mV/V0.04
Creep over 30min %0.03
Temperature effect on zero %/ 0.0012
Temperature effect on output %/ 0.004
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range  -10 to +40
Service temperature range  -25 to +70
Limit load % of R.C. 150
Break load % of R.C. 300
Nominal excitation V 5~12
Max. excitation V 18
Input impedance  400 ±25
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 2
Cable type  4 conductors, Braid Shielded, Black PVC Jacket
Color code  +Exc -Red, +Sig-grn, -Exc-Blk, -Sig- Wht

Interchangeable Products

  Tedea  615

interchangeable with Vishay HBM,Mettler Toledo Load cell

Good quality and long life with competitive price!

Hot selling S type load cell
