651C 300 to 3000g single point load cell for jewellery scale
651C 300 to 3000g single point load cell for jewellery scale
Price
US $15
Model
651C
Min. Order
1 piece

Item specifics

alumninum material
single point type
Rated capacity
300 600 1000 1200 1500 2000 3000g
Accuracy class
OIML C3,C6 standard
Interchangeable with
Vishay-Tedea1004
Application
jewellery scale
Sensitivity
1.0 ±10% (1.6mv 10% available)mV/V
Interchangeable Products
HBM SPL
Creep (From stable to 2min)
0.0033%
Creep over 30min
0.008%
Repeatability
0.01%

Product review

Description

PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) g 300/600/1000/1200/1500/2000/3000
Huazhun Grade  A
Sensitivity mV/V1.0 ±10% (1.6mv 10% available)
Zero balance mV/V0.02
Creep (From stable to 2min) %0.0033
Creep over 30min %0.008
Temperature effect on zero %/ 0.004
Temperature effect on output %/ 0.001
Hysteresis % 0.01
Linearity deviation % 0.01
Repeatability % 0.01
Nominal temperature range  -10 to +40
Service temperature range  -30 to +70
Limit load % of R.C. 150
Break load % of R.C. 200
Nominal excitation V 5~12
Max. excitation V 15
Input impedance  405 ±10
Output impedance  350 ±3
Insulation resistance M >2000
Cable length M 0.4
Cable type  4 conductors, Braid Shielded, Black PVC Jacket

interchangeable with Vishay HBM,Mettler Toledo Load cell

Interchangeable Products

  HBM  SPL
  Tedea   1004
